The SBX is a wide bandwidth transceiver that provides up to 100 mW of output power, and a typical noise figure of 5 dB. The local oscillators for the receive and transmit chains operate independently, which allows dual-band operation. The SBX is MIMO capable, and provides 40 MHz or 120 MHz of bandwidth.
Product Details
The SBX is a wide bandwidth transceiver that provides up to 100 mW of output power, and a typical noise figure of 5 dB. The local oscillators for the receive and transmit chains operate independently, which allows dual-band operation. The SBX is MIMO capable, and provides 40 MHz or 120 MHz of bandwidth.
Frequency: 400MHz – 4.4GHz
Bandwidth: 40 / 120MHz
Gain: 0 – 31.5dB
The SBX supports wide range of applications. Example application areas include WiFi, WiMax, S-band transceivers and 2.4 GHz ISM band transceivers.
